Reference: 303

PFS 400 Hand Impulse Sealer

Kč3,188.00
Tax excluded

Hand Impulse Sealer with the sealing up to 400mm.

In Stock

Hand Impulse Sealer with the sealing up to 400mm.
The maximum thickness of the sealed material 2x0,08mm.

Value Unit Model
PFS–100 PFS-200 PFS-300 PFS-400 PFS-500
Rated supply voltage V 230 230 230 230 230
Rated frequency Hz 50 50 50 50 50
Impulse power W 200 300 400 500 800
Degree of protection - IP 20 IP 20 IP 20 IP 20 IP 20
Maximum sealing length mm 100 200 300 400 500
Time of sealing s 0,2 – 1,5 0,2 – 1,5 0,2 – 1,5 0,2 – 1,5 0,2 – 1,5
Sizes: length x width x height mm 230x70x140 320x80x150 450x80x180 550x90x180 650x100x180
Weight kg 2 2,7 4,5 5,5 6,5

  • Reference
    303

  • Width
    90mm
  • Height
    180 mm
  • Délka
    550 mm
  • Weight
    5.5 kg
  • Jednoduchá tloušťka materiálu
    0.08 mm (80 mic)
  • Compositions
    AL
  • Šířka sváru
    3 mm
  • Maximální délka sváru
    400 mm
  • Napětí
    230 V
  • Frekvence
    50 Hz
  • Jištění
    10 A
  • Stupeň ochrany
    IP 20
  • Příkon
    500 W
  • Svařovací čas
    0.2 - 1.5 sec.
